Drive unit

Battery

Operator type

Walkie

Load capacity

Q (kg)

2000

Service weight (Incl. battery)

kg

205

Tyre type

PU

Tyre size, operator side

(mm)

Ф210x70

Tyre size, load side

(mm)

2xΦ80x60

Lift height

h3 (mm)

115

Overall length

l1 (mm)

1620

Overall width

b1/ b2 (mm)

724

Fork dimensions

s/e/l (mm)

55/150/1150

Fork spread, min/ max

b5 (mm)

560/685

Aisle width, 1000×1200 pallet crossways

Ast (mm)

1739

Aisle width, 800×1200 pallet lengthways

Ast (mm)

1939

Outer turning radius

Wa (mm)

1485

Travel speed, laden/ unladen

km/ h

3.5/ 4

Lifting speed, laden/ unladen

m/s

0.051/ 0.060

Maximum gradeability, laden/ unladen S2 5 min.

%

2/6

Service brake

Electromagnetic

Drive motor rating S2 60 min.

kW

0.65

Lift motor rating at S3 15%

kW

0.84

Battery voltage/ rated capacity (5h)

V/ Ah

24/ 65

Battery weight

kg

45

Battery compartment dimensions l/w/h

mm

260/169/ 215

Battery type

Maintenance free battery

Type of drive control

DC 直流

Manufacturer

CURTIS 柯蒂斯
